Heat Seal Pull Off Test (Simple Manual Test)

See other test videos
Description Measurement Example Videos
CONTACT
  1. Force Measurement IMADA
  2. SOLUTIONS
  3. Peel Test
  4. Heat Seal Pull Off Test (Simple Manual Test)

Description FAVORITES

Heat Seal Pull Off Test (Simple Manual Test)

T Peel

Simple Test

Stand Unrequired

It is a simple manual heat seal pull off test for confectionery and food packaging. This method uses a force gauge with a jig to hold one side of the testing sample and pull the other side by hand to measure the peeling force (welding force). The heat seal has the role of protecting the contents, and the heat seal strength changes depending on the temperature, pressure, and time of welding. This measurement is ideal in quality control to optimize heat seal strength. Alternatively, there is also a solution using a motorized test stand that can test based on ISO and JIS standards.

inquiry number

3P2007A

Present the “inquiry number” below when you contact us, for prompt assistance.

Related sample

  • Plastic bag
  • Adhesive
  • Packaging material

Measurement Example Videos

Product used

Digital Force gauge

DSV-50N

1

Optional Attachment

FC-20

1

Cautions

This video shows the testing image of objective sample. Some samples may not be suitable to measure with this configuration depending on their materials or shapes.
The example of product configuration is for your reference only. It varies depending on sample, measurement method and testing capacity.
The products used in this video may differ from the example of product configuration.
Please select the right product model for the product configuration. Refer to the specification of each product for the compatibility.
