Opening Force Test of Flat Folded Carton

See other test videos
Description Measurement Example Videos
CONTACT
  1. Force Measurement IMADA
  2. SOLUTIONS
  3. Compression Test
  4. Opening Force Test of Flat Folded Carton

Description FAVORITES

Opening Force Test of Flat Folded Carton

Bending Force

Customized Item

Graph

The durability of cardboard is getting more important to protect products during distribution, which causes companies value its quality management. For instance, a box-making machine, also known as a carton former, opens the folded carton to make a carton box, however, the machine may shut down due to the variation of force to open folded cartons. Thus, the management and testing of opening force of flat-folded carton is necessary. This video shows how to measure the force when opening the flat folded carton by using IMADA customized attachment and testing equipment. Moreover, By using the graphing software, the transition of the force to open the flat-folded carton can be checked visually.

inquiry number

3A5002A

Present the “inquiry number” below when you contact us, for prompt assistance.

Related sample

  • Corrugated box
  • Paper carton

Measurement Example Videos

Product used

Digital Force gauge

ZTS-100N

1

Motorized Test Stand

MX2-500N-L

1

Customized Item

Flat pack carton opening jig

1

Optional cable

CB-528

1

Optional software

Force Recorder Standard

1

Cautions

This video shows the testing image of objective sample. Some samples may not be suitable to measure with this configuration depending on their materials or shapes.
The example of product configuration is for your reference only. It varies depending on sample, measurement method and testing capacity.
The products used in this video may differ from the example of product configuration.
Please select the right product model for the product configuration. Refer to the specification of each product for the compatibility.
