Resize & Modification
We propose modifications to the specifications of standard products to adapt them to the sample geometry, measurement conditions, and operating environment.
Resize & Modification
Inquiry No.1T024
Press Test Fixture (Wide Size)
This custom-made attachment enlarges the width of PR series for such as larger retort pouch or other larger packaging. Contact us for special requirement on size and material.
For more info
Inquiry No.1T030
Remote Control Switch for Motorized Test Stand
This custom-made product enables remote control of motorized test stand. Contact us for your special requirements.
For more info
Inquiry No.1T031
Semi-Customized Compression Attachments
The size, materials and capacity of attachment can be changed to suit for your samples.* We are not able to offer semi-customized attachment of some shapes or materials.* We do NOT accept any request for dangerous, explosive, harmful, or toxic samples.
For more info
Inquiry No.1T032
Large Size of Compression Tester
Ideal for compression test of large size of samples such as car’s dashboard.
For more info
Inquiry No.1T033
Large Size of 90 Degree Peel Tester
Enables you to test A3 size of samples or samples bonded on three-dimensional objects.
For more info
Inquiry No.1T046
Force Control Cable with Signal Output Box
A customized cable with a signal output box branched from connecting a force gauge to a motorized test stand and a linear scale. The cable can output analog voltage and Rec signals.
For more info
Inquiry No.1T052
Manual Test Stand with Displacement Output Option
It is economical solution for force-displacement analysis. This custom-made manual test stand enables force-displacement analysis by adding displacement output option to it.
For more info
Inquiry No.1T060
Cutting Base Plate with groove and knife edge probe
Cutting Base Plate with groove and knife edge probe for our food texture analyzer, FRTS series. These are customized products based on FR-GT series and FR-NB-80. Due to the direction of the groove on the plate and extended blade, these toolscan improve your test productivity.
For more info
Inquiry No.1T061
Upper attachment for 4-point bending test
Upper attachment for 4-point bending test. The round edge is movable to fit your test specification. We can adjust the diameter of the round edge and also can make fixture for this attachment.
For more info
Inquiry No.1T065
Main shaft stopper with a butterfly screw for MTS series
Stopper with a butterfly screw to adjust the height of the main shaft of MTS series, motorized torque stands. Standard MTS series require hexagon wrenches to adjust the height of its main shaft, but this customization enables you to adjust the main shaft height without any tool.
For more info
Inquiry No.1T037
Wide Rubber Roller for Peel Test
This custom-made attachment enlarges roller width of rubber roller for peel test APR-97 to meet your needs. Contact us for special requirement on size, material, and weight of the roller.
For more info
Inquiry No.1T038
Motorized Rubber Roller for Peel Test
The motorized rubber roller for peel test allows bonding of a sample at a certain pressure. The roller moves at a certain speed automatically to enhance testing efficiency and accuracy.
For more info
Inquiry No.1T039
Peel Fixture for Packaged Cooked Rice Lid
This custom-made fixture is designed for 45 degree peel test of film lid for soft and rectangle-shaped container such as packaged cooked rice.
For more info
Inquiry No.1T068
Cam grip with spring
This cam grip with spring is ideal for hard sample such as tube. The equipped spring controls the cam return, ensuring grip the sample firmly from the beginning.
For more info
Inquiry No.1T069
Wedge Grip Without Adaptor
This customized wedge grip without adaptor allows you to extend the stroke of the test stand. It is ideal for measurements that do not require jig pivoting but require a long stroke.
For more info
Inquiry No.1T071
Customized Peeling Tester
This peel tester is customized from standard IPTS series to meet particular requirements including enlargement of product width and film clip's gripping width, extension of stroke (peeling length), and adding function to adjust position of load cell.
For more info
Inquiry No.1T072
Test Stand with 3-stage Force/Displacement setting/holding function
This customized EMX product is designed for material characteristic evaluation test of sample such as spring. It enables three-stages compression test holding at desired force or displacement. Just by pressing a start button after setting, 3-stage test is automatically conducted, improving measurement efficiency.
For more info
