Standard High Capacity Model Digital Force Gauge

ZTS series (High Capacity)

ZTS series (High Capacity)

Description Relevant Information and Materials Relevant Products User Guide Videos
CONTACT
  1. Force Measurement IMADA
  2. PRODUCTS
  3. Digital Force Gauges
  4. ZTS series (High Capacity)

Description Add to favorites

ZTS-5000N ZTS-5000N

ZTS Series (high capacity) Standard Set ZTS Series (high capacity) Standard Set

ZTS-5000N

ZTS Series (high capacity) Standard Set

Hi Force

Hi Repeatability

Multi Function

OLED Disp

Next Series

Hi Res GRF

Standard high capacity type digital force gauge has capacity of 5000N, and the data is acquired at a rate of 2000 data/s, hence even peak values are accurately acquired. Smooth curve can be drawn when data is graphed. Software for data management on a PC is also included. Graphing data in real time comes in option. Next Series digital force gauge with firmware Ver. 5 or later offers improved measurement stability with less noise, and optional functions and software can be downloaded from a dedicated website (IMADA Connected). Some functions require connection to separately-sold products.

Feature

  • High sampling rate (2000Hz) for accurate results, capturing small changes and accurate peak values by following rapid changes of force
  • Reduces risk of misreading values with easy-to-read high luminance organic EL display. Allows customers to customize the contents for the three sections of the display screen
  • Improves testing versatility by various data output options such as USB, wireless, and serial communication, which allows data management on a PC and combination with external devices
  • Allows easy data acquisition and management with the included USB cable and software. By using with optional software real-time force-time graphing also possible
  • Next Series (Firmware Ver.5 or later) equips extended functions such as firmware updates and various software downloads from IMADA download site

User Guide Videos

Setting

Set Multi Display, Set Force Bar Graph

Setting

Invert The +/- Signs

Setting

Set High Low Setpoints

Setting

Reverse The Display

Setting

Set Track Mode, Set Peak Mode, Set 1st/2nd Peak (Only for ZTA)

Setting

Install Software Force Logger

Setting

Install Force Logger Driver (ZT Series)

Setting

Install Force Logger Driver (Wireless Unit)

Setting

Use Force Logger in Wired/Wireless Mode

Setting

Select Items to Show and Save, Change and Save the Settings of Force Gauge in Force Logger

Data Record

Record/Send Data

Data Record

Save Data, Open the Saved File by Force Logger

Data Record

Export to CSV, Print Data, Copy and Paste Data by Force Logger

Data Record

Acquire/Delete Data by Force Logger

Maintenance

The Procedures of Daily Inspection

Maintenance

Battery Replacement

Troubleshooting

Handling Precaution for Avoiding the Sensor Fault
