Quad Sensor Measuring Amplifier

QSMA-400

QSMA-400

Description Relevant Information and Materials Relevant Products
CONTACT
  1. Force Measurement IMADA
  2. PRODUCTS
  3. Digital Force Gauges
  4. QSMA-400

Description Add to favorites

QSMA-400 QSMA-400

Dedicated Software Quad Graph Drawer Dedicated Software Quad Graph Drawer

QSMA-400

Dedicated Software Quad Graph Drawer

Ext Load Cell

Multi Function

Multi Purpose

eZ-Connect

Max 4 Connections

Multi Simul. Graphs

A measurement amplifier can be used with any of four assorted choices: load cells, strain gauges, and voltage sensors.
Linear scale (angle meter) and contact signals are also possible for input. By using the downloadable software, all measurements can be displayed in real-time. Continuous data can be recorded and graphed, allowing correlations between measurements to be analyzed.

Feature

  • Possible to input a total of 4 channels from the force, torque, strain, and voltage. In addition, input displacement (angle) and contact signals are also available.
  • High-speed sampling (2000Hz) to track sudden force changes and accurately capture peak values and small force changes.
  • With the software downloaded, the data can be displayed in real time. Continuous data recording and time graph drawing are also possible.
  • The software is available for download from IMADA Connected. (User registration and QSMA-400 product registration required .)
  • Without accuracy adjustment, eZ-ConnectIt can be attached and used.
