Fine Point Chuck
FP-50/51
FP-50/51
Description Add to favorites
FP-50
Wire Shape Sample
Tight Space
Light Weight
Lo-Mid Force
FP-50/51 is fine point chuck with 50N capacity. It is ideal for tension testing of fine samples such as fiber and hair where space is limited. (the Max. opening width 0.5mm)
Feature
- Ideal for tension testing of fine samples such as fiber and hair where space is limited (the Max. opening width 0.5mm)
- Suitable for testing requires low capacity due to compact and light-weight design
- Stainless standard type (FP-50) and aluminum light type (FP-51) available
Relevant Information and Materials
Example of Product Configuration
FP-50
Features
FP-50 enables you to clamp a test sample even in a narrow space.
This testing system offers a simple solution of tensile test up to 100N.
inquiry number
1F2002A
Present the “inquiry number” below when you contact us, for prompt assistance.
Product used
Digital Force Gauge
DST-200N
1
Motorized Test Stand
MX-500N
1
Optional Attachment
FP-50
2
Cautions
It might NOT be suitable for slippery or highly deformable samples.
Refer to specifications of each product for details.
Product configuration varies depending on the shape and characteristic of the sample, and measurement conditions.
The recommended capacity of measurement instruments varies depending on the expected force to be loaded.
Features
FP-50 enables you to clamp a test sample even in a narrow space.
This testing system offers a simple solution of tensile test up to 100N.
A vice grip is used on the test stand's side, handling a wide range of test samples.
inquiry number
1F2002B
Present the “inquiry number” below when you contact us, for prompt assistance.
Product used
Digital Force Gauge
DST-200N
1
Motorized Test Stand
MX-500N
1
Optional Attachment
FP-50
1
Optional Attachment
GT-30
1
Cautions
It might NOT be suitable for slippery or highly deformable samples.
Refer to specifications of each product for details.
Product configuration varies depending on the shape and characteristic of the sample, and measurement conditions.
The recommended capacity of measurement instruments varies depending on the expected force to be loaded.
Features
FP-50 enables you to clamp a test sample even in a narrow space.
This testing system offers a functional & versatile solution of tensile test up to 100N.
inquiry number
1F2002C
Present the “inquiry number” below when you contact us, for prompt assistance.
Product used
Digital Force Gauge
ZTS-100N
1
Motorized Test Stand
MX2-500N
1
Optional Attachment
FP-50
2
Optional Cable
CB-528
1
Cautions
It might NOT be suitable for slippery or highly deformable samples.
Refer to specifications of each product for details.
Product configuration varies depending on the shape and characteristic of the sample, and measurement conditions.
The recommended capacity of measurement instruments varies depending on the expected force to be loaded.
Features
FP-50 enables you to clamp a test sample even in a narrow space.
This testing system offers a functional & versatile solution of tensile test up to 100N.
A vice grip is used on the test stand's side, handling a wide range of test samples.
inquiry number
1F2002D
Present the “inquiry number” below when you contact us, for prompt assistance.
Product used
Digital Force Gauge
ZTS-100N
1
Motorized Test Stand
MX2-500N
1
Optional Attachment
FP-50
1
Optional Attachment
GT-30
1
Optional Cable
CB-528
1
Cautions
It might NOT be suitable for slippery or highly deformable samples.
Refer to specifications of each product for details.
Product configuration varies depending on the shape and characteristic of the sample, and measurement conditions.
The recommended capacity of measurement instruments varies depending on the expected force to be loaded.
